Sliding gate motorCAME BKV 2500 kg
AED 6,800
Installation available, ask on WhatsApp
Delivery in the UAE, ask on WhatsApp for timing
54Protection
1000Max thrust
230Power supply
300Power
12Speed
Overview
Full description
CAME BKV 2500 KG
CAME BKV 2500 KG Sliding Gate Motor in UAE
CAME BKV 2500 KG Sliding Gate Motor in UAE
- CAME BKV 2500 KG 801MS-0320 BKV25AGS
- Robust industrial 36V sliding gate motor designed for gates up to 2500 kg,
- with IP54 protection.
- It features adaptive Speed and Torque Technology
- to ensure smooth and consistent movements over time.
- Settable through a graphical display with also 4 configurable
- safety inputs for direct management of resistive safety edges.
- Max. leaf weight : up to 2500 kg
- Max. leaf length : 20 m
- Use : Continuous duty
Technical Data:
- Protection rating (IP) : 54
- Absorption (A) : 10
- Thrust (N) : 1000
- Power supply (V – 50/60 Hz) : 230
- Power (W) : 300
- Power supply to motor (V) : 36
- Manouvering speed (m/min) : 12
- Max. weight of leaf (kg) : 2500
Specifications
Power
- Power supply (V – 50/60 Hz)
- 230
- Power (W)
- 300
- Power supply to motor (V)
- 36
Performance
- Absorption (A)
- 10
- Thrust (N)
- 1000
- Manouvering speed (m/min)
- 12
Environment
- Protection rating (IP)
- 54
- Max. weight of leaf (kg)
- 2500
FAQ
Is it rated for outdoor use?
Protection rating: 54.
What power supply does it need?
230.
Do you install it?
Yes, installation is available. Send a photo of your gate and your location on WhatsApp for a price.
Not sure it fits your gate?Send us a photoAsk
